The Evolution
Continues
The most integrated and adaptable Steadicam system ever created.
The Evolution
Continues
The most integrated and adaptable Steadicam system ever created.
Product Highlights
Features Steadicam Volt technology directly built-in
Modular - customizable to your preferences
Lighter weight and lower cost high-end system
Product Highlights
Features Steadicam Volt technology directly built-in
Modular - customizable to your preferences
Lighter weight and lower cost high-end system
What is it?

The Steadicam M-2 is the most integrated and adaptable Steadicam system ever created. Not only does the M-2 offer a lighter weight and lower cost high end system, it also features the revolutionary Steadicam Volt™ technology directly built in for a sleeker, more versatile rig.

The Volt electronics, which measure the roll, tilt and pan motion of the camera, are seamlessly integrated into the camera top stage to decrease the distance between the top of the gimbal and the top of the stage as well as reduce weight. Volt controls can be configured on either side of the stage for unobstructed access for the operator.

The “M” in M-1 stands for “modular” and the M-2 takes the concept of modularity to a whole new level. Almost every component of the sled offers options for customization.

Rigid carbon fiber posts are available in a variety of lengths and diameters (1.75” 2 or 3 section post 1.58” standard or short post). The sled base can be built with either Gold mount or V-lock battery plates. A hot-swappable 3rd battery mount is available. The lightweight redesigned quick-release monitor mount uses industry-standard 60mm rod spacing and is compatible with a variety of professional monitors. And both standard and tilt top stages are available with or without Volt electronics built in.

In total the M-2 can be configured in multiple combinations to suit each operator’s preferences, or additional pieces can be purchased for adapting the sled based on the needs of the project.

About the Volt.

For those who have not yet experienced the Volt, this revolutionary technology is designed to complement rather than oppose normal operating by actively assisting in holding virtually any tilt or roll angle, including a perfectly level horizon. This gentle assistance helps remove the effects of wind, acceleration, or natural body movement in the captured image. The amount of resistance can be fine-tuned to match each operator’s personal preference and provides haptic feedback that emulates the fluid-like friction in a tripod head. The Volt assistance can be engaged or disengaged with a single push of a button.

The Volt works in two parts. A control board is either mounted on the top stage, or directly integrated in the case of the M-2. The control board measures the movement of the camera using an accelerometer and gyroscope sensors and communicates with the Volt motor drive unit mounted on the gimbal of the rig. The motor drive unit applies the desired torques based on the operator’s choice to maintain the tilt and roll angles set by the operator. Operators have the ability to work against this torque to adjust angles on the fly with the benefit that when they release pressure the sled returns to the preset angle without pendulating.

What is it?

The Steadicam M-2 is the most integrated and adaptable Steadicam system ever created. Not only does the M-2 offer a lighter weight and lower cost high end system, it also features the revolutionary Steadicam Volt™ technology directly built in for a sleeker, more versatile rig.

The Volt electronics, which measure the roll, tilt and pan motion of the camera, are seamlessly integrated into the camera top stage to decrease the distance between the top of the gimbal and the top of the stage as well as reduce weight. Volt controls can be configured on either side of the stage for unobstructed access for the operator.

The “M” in M-1 stands for “modular” and the M-2 takes the concept of modularity to a whole new level. Almost every component of the sled offers options for customization.

Rigid carbon fiber posts are available in a variety of lengths and diameters (1.75” 2 or 3 section post 1.58” standard or short post). The sled base can be built with either Gold mount or V-lock battery plates. A hot-swappable 3rd battery mount is available. The lightweight redesigned quick-release monitor mount uses industry-standard 60mm rod spacing and is compatible with a variety of professional monitors. And both standard and tilt top stages are available with or without Volt electronics built in.

In total the M-2 can be configured in multiple combinations to suit each operator’s preferences, or additional pieces can be purchased for adapting the sled based on the needs of the project.

About the Volt.

For those who have not yet experienced the Volt, this revolutionary technology is designed to complement rather than oppose normal operating by actively assisting in holding virtually any tilt or roll angle, including a perfectly level horizon. This gentle assistance helps remove the effects of wind, acceleration, or natural body movement in the captured image. The amount of resistance can be fine-tuned to match each operator’s personal preference and provides haptic feedback that emulates the fluid-like friction in a tripod head. The Volt assistance can be engaged or disengaged with a single push of a button.

The Volt works in two parts. A control board is either mounted on the top stage, or directly integrated in the case of the M-2. The control board measures the movement of the camera using an accelerometer and gyroscope sensors and communicates with the Volt motor drive unit mounted on the gimbal of the rig. The motor drive unit applies the desired torques based on the operator’s choice to maintain the tilt and roll angles set by the operator. Operators have the ability to work against this torque to adjust angles on the fly with the benefit that when they release pressure the sled returns to the preset angle without pendulating.

Further Information

Manuals:

Click here to view the Steadicam M-2 instructional manual.

Test Drive:

We will be offering Test Drive opportunities of early production model M-2 rigs in Los Angeles, New York, and London. If you are interested in the chance to try out the new M-2 ahead of ordering contact us through the form below and specify Test Drive.

Financing:

We will be developing financing options for purchases of the Steadicam M-2 to make it even easier to upgrade to the newest, most feature rich stabilizer rig on the market.

Want to learn more?

To request a Test Drive, inquire about early ordering, or keep up to date on future developments, please sign up using the form below.

Fill out my online form.
Further Information
Manuals:
Click here to view the Steadicam M-2 instructional manual.

Test Drive:
We will be offering Test Drive opportunities of early production model M-2 rigs in Los Angeles, New York, and London. If you are interested in the chance to try out the new M-2 ahead of ordering contact us through the form below and specify Test Drive.

Financing:
We will be developing financing options for purchases of the Steadicam M-2 to make it even easier to upgrade to the newest, most feature rich stabilizer rig on the market.

Want to learn more?
To request a Test Drive, inquire about early ordering, or keep up to date on future developments, please sign up using the form below.
Fill out my online form.
